Magnesium ion selective electrode

NT Sensors manufactures and puts at your disposal high quality, reliable, fast and affordable magnesium ion selective electrodes based on the latest nanotechnology innovative research.

Above all, some places where it is present and analysis are more useful are; for example:

  • Perforation muds
  • Minery
  • Drinking water
  • Mineral water and seawater
  • Farming

In conclusion, this sensor provides major precision in water hardness and it’s, in fact, one of the needed components to get to know that value through a mathematical formula. The total hardness is the sum of calcium, magnesium, barium and strontium ions. Since only calcium and magnesium are present significantly in drinking water, the hardness is entirely determined by their content.

Magnesium ion selective electrode

Magnesium ion selective electrodeREF: M024
Diameter: 2,5 mm
Minimum sample volume: 0,25 ml

More information about
Mini 2.5
View product

Specifications

Range (concentration): 2.4 to 2.400 mg/L
Reproducibility (precision): ±20% of full scale (calibrated 10 to 1000 mg/L)
Interfering ions: K+, Ca2+
pH range: 3 to 8.5 (no pH compensation)
Temperature range: 4 – 40°C (no temperature compensation)
Electrode slope: 24 ±5 mV
Electrode resistance: 1–4 MΩ
Immersion minimum: 2 mm
Body diameter: see different sensors

Where is Magnesium measurement required so far?

The magnesium ion selective electrode sensor is designed to provide increased accuracy in water hardness, drilling muds, mining, drinking water, mineral water and seawater. The Mg+2 ISE can also be accurately applied to the monitoring of total water hardness assessments.Also, it is mainly found in mineral deposits.
Finally, magnesium plays an important role in both plants and animals. In plants, magnesium is the central ion of chlorophyll. In vertebrates, magnesium is essential, especially within cells. Magnesium is also widely used for technical and medical applications ranging from the production of alloys, pyrotechnics and fertilisers to health care.
